If you are in web development, maybe you've heard of Sass, Less, Pug, Stylus etc. All these are pre-processors. In this tutorial we're going to build nothing less than a functional css pre-processor from scratch with variables and functions. This type of new language is called source-to-source compiled. If you are thrilled, i hope not to disappoint you.
Charting The Routes
First let’s see what we’ll be doing. We’ll call the language DotDot with extention .dot
When designing a new language, it’s good to spend sometimes on design. If you have something that really flows, you can start coding.
Here is a DotDot snippet:
x = 1
y = 5
x-y-z = 6
col-z = berry
@f{
border: 10px solid black;
border-radius: 50%;
}
.add{
color:white;
background-color: rgb(3, 4, 5);
}
#ad{
color: rgb(x, 4, 5);
}
.a div a{
color: ..col-z;
@f
}
which compiles to this:
.add{
color: white;
background-color: rgb(3,4,5);
}
#ad{
color: rgb(1,4,5);
}
.a div a{
color: berry;
border: 10px solid black;
border-radius: 50%;
}
Dissecting Design
Let’s see what features we included
Variables
x = 1
y = 5
x-y-z = 6
col-z = berry
We see that
- we don’t need to specify a specifier like $ or var in Js.
- we can add – in the variable name
We can also call variables in function values
rgb(x, 4, 5);
And in attribute values
color: ..col-z;
Where .. denotes a variable call in attribute directly.
Functions
@f{
border: 10px solid black;
border-radius: 50%;
}
Functions are denoted by an @ sign. These are called as in the following case where it expands into the properties it contains.
.a div a{
color: ..col-z;
@f
}
That is enough complexity to deal with. Let’s start!
import copy ### we have just one import
and we put the source as a variable
source = '''
x = 1
y = 5
x-y-z = 6
col-z = berry
@f{
border: 10px solid black;
border-radius: 50%;
}
.add{
color:white;
background-color: rgb(3, 4, 5);
}
#ad{
color: rgb(x, 4, 5);
}
.a div a{
color: ..col-z;
@f
}
'''
Defining Constants
We’ve bundled our constants in a class.
class SYM:
LEFT_BRACE = '{'
RIGHT_BRACE = '}'
LEFT_ROUND = '('
RIGHT_ROUND = ')'
NEW_LINE = '\n'
TAB = ' '
COLON = ':'
SEMI_COLON = ';'
SPACE = ' '
COMMA = ','
EQUAL = '='
UNION = '-'
DOT = '.'
AT = '@'
We then define our keywords
KEYWORDS = (SYM.LEFT_BRACE, SYM.RIGHT_BRACE, SYM.NEW_LINE, SYM.TAB, SYM.COLON,
SYM.SEMI_COLON, SYM.SPACE, SYM.RIGHT_ROUND, SYM.LEFT_ROUND, SYM.COMMA, SYM.EQUAL)
Building the Lexer
The code for the lexer is from this lexer tutorial. Please go over it if you feel the need to. Here we converted the code into a class with a get_lexeme method. The method gives us a list. The dotdot snippet above gets converted to the list held in lexemes variable below.
Here is our lexer class:
class Lexer:
def __init__(self, source: str, KEYWORDS: list):
self.white_space = SYM.SPACE
self.KEYWORDS = KEYWORDS
self.lexeme = ''
self.lexemes = []
self.string = source
def get_lexemes(self) -> list:
for i, char in enumerate(self.string):
if char != self.white_space and char != SYM.NEW_LINE:
self.lexeme += char ### adding a char each time
if (i+1 < len(self.string)): ### prevents error
if self.string[i+1] == self.white_space or self.string[i+1] in KEYWORDS or self.lexeme in KEYWORDS or self.string[i+1] == SYM.NEW_LINE: ### if next char == ' '
if self.lexeme != '':
self.lexemes.append(self.lexeme)
self.lexeme = ''
return self.lexemes
Then we declare our basic variables:
v = Lexer(source, KEYWORDS)
lexemes = v.get_lexemes()
lexemes.append('') ### appending an unused last element to properly dump all values
lexemes is now equal to
['x', '=', '1', 'y', '=', '5', 'x-y-z', '=', '6', 'col-z',
'=', 'berry', '@f', '{', 'border', ':', '10px', 'solid',
'black', ';', 'border-radius', ':', '50%', ';', '}', '.add',
'{', 'color', ':', 'white', ';', 'background-color', ':',
'rgb', '(', '3', ',', '4', ',', '5', ')', ';', '}', '#ad',
'{', 'color', ':', 'rgb','(', 'x', ',', '4', ',', '5', ')',
';', '}', '.a', 'div', 'a', '{', 'color', ':', '..col-z',
';', '@f', '}', '']
With such separated data, it’s much easier to proceed!
The Concept of Memory
Next we define a dictionary to hold all our variables.
memory = {}
where
x = 1
will become this later on:
{'x':'1'}
to retrieve it we’ll just do
memory['x']
The Concept of Tree
We’ll have a dictionary called tree
tree = {}
which will hold the converted code as
{
'@f': {
'border': '10px solid black',
'border-radius': '50%'
},
'.add': {
'color':'white',
'background-color': 'rgb ( 3 , 4 , 5 )'
}, '#ad': {
'color': 'rgb ( x ,4 , 5 )'
},
'.a div a': {
'color': '..col-z',
'@f': ''
}
}
Our next step will exactly be this: converting the lexemes list into this dictionary
Generating The Tree
To keep track of where we are, we’ll have a series of variables taking True/False values (on/off)
Setting Up Holders
id_string = ''
last_id_string = ''
last_attribute = ''
current_attribute = ''
current_value = ''
len_lexemes = len(lexemes)
id string will hold like #add, .x a div etc
the last_ variables just hold variables that are not emptied upon leaving the sub section
Setting Up Flags
We’ll have 3 flags.
One when we are starting a block, which will become true when encountering a { and false when encountering a }
An attribute is color in color:black;
The attribute ongoing will become true when passing over { and ; and will become false when passing over :
value_ongoing will become true when going over : and false when going over ;
block_ongoing = False
attribute_ongoing = False
value_ongoing = False
We’ll start looping over the list and implement what we described of the flags above
for i, lex in enumerate(lexemes):
if i+1 < len_lexemes:
next_lexeme = lexemes[i+1]
prev_lexeme = lexemes[i-1]
if lex == SYM.LEFT_BRACE:
block_ongoing = True
attribute_ongoing = True
continue
elif lex == SYM.RIGHT_BRACE:
block_ongoing = False
statement_ongoing = False
attribute_ongoing = False
value_ongoing = False
continue
if lex == SYM.COLON:
value_ongoing = True
attribute_ongoing = False
continue
elif lex == SYM.SEMI_COLON:
value_ongoing = False
statement_ongoing = False
attribute_ongoing = True
continue
Continue is needed as once we have activated a flag, we have no work to do, we move on.
Dealing with variables
To assign variables, we just wait for the = sign then continue.
Then when going over a variable name or a value we just prevent the loop from continuing by using continue
if lex == SYM.EQUAL:
memory[prev_lexeme] = next_lexeme
continue
elif next_lexeme == SYM.EQUAL or prev_lexeme == SYM.EQUAL:
continue
Where The Tree Builds
Now we’ll make use of the flags
if not block_ongoing:
id_string += lex + ' '
elif block_ongoing:
if id_string:
tree[id_string.strip()] = {}
last_id_string = id_string.strip()
id_string = ''
Here we are dealing with the block id, example #add in #add {}. We did
tree[id_string.strip()] = {}
here is an example tree at this point
{
'.add': {}
}
Using the same principle, we’ll do so for the attribute
if attribute_ongoing:
current_attribute += lex
elif not attribute_ongoing:
if current_attribute:
tree[last_id_string][current_attribute] = ''
last_attribute = current_attribute
current_attribute = ''
Here is an example tree at this point
{
'.add': {
'color':''
}
}
and value
if value_ongoing:
current_value += lex + ' '
elif not value_ongoing:
if current_value:
tree[last_id_string][last_attribute] = current_value.strip()
last_value = current_value.strip()
current_value = ''
Here is an example tree at this point
{
'.add': {
'color':'white'
}
}
That snippet ends our tree-building block
Replacing Values
Now let us see how to replace variable names in functions like rgb() and rgba()
def parseFunc(f):
v = f.split(SYM.LEFT_ROUND)
name = v[0]
vals = v[1][:-1].replace(SYM.SPACE, '')
values = vals.split(SYM.COMMA)
for i, v in enumerate(values):
if not v.isnumeric():
values[i] = memory[v]
return '{}({})'.format(name.strip(), ','.join(values))
Here we replace rgb(x, 4, 5) to rgb(1, 4, 5) by replacing the x by 1 in the memory dictionary. To build a CSS pre-processor from scratch, we have to take all cases, which we’ll do after.
Transforming The Tree Into It’s Final Form
Now we need to pass over the tree once again and expand functions, replace values, including the use of our defined function above.
Technically we can’t change a dictionary while iterating over it. We have to copy it to break references. We have to deepcopy it.
ntree = copy.deepcopy(tree)
then we iterate over:
for block_name in ntree:
properties = ntree[block_name]
if block_name[0] == SYM.AT:
continue
Now, if we get the first symbol of the id as a @, we just skip it as we don’t need to expand the definition.
for element in properties:
value = properties[element]
if SYM.LEFT_ROUND in value:
tree[block_name][element] = parseFunc(value)
Next we say if there is a ( in the value, it denotes a function like rgb(). In that case we use our function parseFunc.
if SYM.DOT in value:
tree[block_name][element] = memory[value.strip(SYM.DOT)]
Next we see a . in the value, we go see in the memory dictionary and replace it
if SYM.AT in element:
del tree[block_name][element]
tree[block_name].update(tree[element])
Next we see the @
That also shows the advantage of using a data structure over plain strings.
Compiling To Normal Css
Now we can compile it to normal CSS, we’ll just print it for now (you can file= in print btw)
for key in tree:
if key[0] == SYM.AT:
continue
print(key, '{', sep='')
for elem in tree[key]:
print('{}{}: {};'.format(SYM.TAB, elem, tree[key][elem]))
print('}\n')
which produces
.add{
color: white;
background-color: rgb(3,4,5);
}
#ad{
color: rgb(1,4,5);
}
.a div a{
color: berry;
border: 10px solid black;
border-radius: 50%;
}
The Future of It
This was done without a safety net and lacking lot of cool features but it is done to demonstrate that with some normal programming logic, you can set up something cool. It was my usual linkedIn Python Project of The Week.
If you want to build a CSS pre-processor from scratch based on indentation (like stylus), use this tutorial.
What's the next thing/s to add? Comment it below!
Github Link: https://github.com/Abdur-rahmaanJ/dotdot
Images from unsplash
— Abdur-Rahmaan Janhangeer
